ItemParameters
Sweeping Width1550–2500mm (telescopic adjustable)
Main Brush Width800mm
Working Efficiency15,000–22,500 m²/h
Waste Bin Volume380L
Drive Motor2200W
Main Roller Brush Motor1000W
Side Brush Motor4×120W
Fan Motor2×500W
Side Brush DiameterFront:700mm ×4
Water Tank800L large-capacity water tank
Power Source48V, 150–200Ah maintenance-free Tianneng battery
Travel Speed0–12 km/h
Operating Speed0–9 km/h
Total Weight1550 KG
Overall Dimension3630×2500×2600 mm
Vacuum Filtration Area10 m²
Gradeability25%
Electric Pump Power1500W / 150 bar
Product Features
High-pressure Washing Configuration
– Equipped with 10m high-pressure hose with auto hose reel (15m hose optional);
– Comes with handheld high-pressure spray gun, four types of floor spray nozzles, front spray control valve, and dedicated 800L plastic water tank;
Built-in fire-filling inlet,tank cleaning opening AND tank drain outlet.
– Electrically adjustable working pressure: 50–150 BAR, max flow rate:15 L/min.
Optional Extra Accessories
Quad-fan set, quadruple filter elements, four-shock dust suppression sweeping kit, high-pressure washing system, swing spray nozzle, high-range water cannon, front & rear flushing system, LED display screen.
Core Advantages
1. Fitted with new-energy vehicle maintenance-free battery and intelligent matching charger.
2. Constant-temperature controller with durable build; automatic over-load & under-voltage protection ensures safe sweeping operation.
3. Complete vehicle wiring diagram provided for convenient maintenance & troubleshooting.
4. Intelligent auto fault alarm system equipped.
