| Component Name | Item | Specification & Parameter |
| Complete Vehicle | Model No. | ZS-04 |
| Total Sweeping Width | 2100mm |
| Main Brush Width | 750mm |
| Working Efficiency | 9000–16000 m²/h |
| Continuous Working Time | 2–6 h |
| Waste Bin Volume | 180L |
| Side Brush Diameter | 600mm |
| Travel Speed | 0–14 km/h |
| Overall Dimension | 2300×2100×2100 mm |
| Water Tank Capacity | 200L |
| Vacuum Filter Area | 12 m² (extended filter cartridge) |
| Tire Spec | Front: 400-8 / Rear: 400-8 solid tires |
| Control Mode | Intelligent control system (timed filter dust shaker function) |
| Surface Treatment | Full vehicle electrophoretic baking paint |
| Warning Lights | Front Lamp | 4-way LED headlight |
| Tail Lamp | Integrated tail lamp for turn signal, brake & running light |
| Warning Beacon | Top-mounted operation warning lamp |
| Reverse Light | Rearview camera for reversing |
| Storage Battery | Battery Type | Maintenance-free lead-acid battery (Lithium battery optional) |
| Rated Capacity | Standard: 48V100AH; Optional: 48V150AH lead-acid |
| Motors | Traction Motor | 1000W intelligent variable speed |
| Main Roller Brush Motor | 1000W |
| Side Brush Motors | 4 units × 100W |
| Rated Voltage | 48V |
| High-Pressure System | High-Pressure Water Pump | 1000W (Max. working pressure: 110kg) |
| Handheld High-Pressure Water Gun | 1 set with adjustable nozzles |
| High-Pressure Hose Reel | 10m |
| Rearview Mirror | Model | Special for road sweepers |
