Floor Sweeper，Model:ZS-01
| Unit | Specification | |
| Model | / | ZS-01 |
| Overall Dimension(L×W×H) | mm | 1950*1900*1900 |
| Drive Power | w | 1500 DC Motor |
| Power Source | V/a h | 48/103（4 pcs）Maintenance-free Battery |
| Sweeping Width | mm | 1900 |
| Whole Vehicle Material | / | Reinforced Steel Plate with Plastic Spraying Coating |
| Steering & Braking Mode | / | Steering Wheel + Hydraulic Double-disc Brake, Intelligent Anti-slope Function |
| Electronic Control Circuit | / | National Standard Integrated Waterproof Wiring Harness |
| Working Efficiency | ㎡/h | 13000 |
| Continuous Working Hour | h | 4-6 |
| Max. Grade ability | % | 25 |
| Max. Driving Speed | Km/h | 12 |
| Water Tank Capacity | L | 100 |
| Garbage Bin Capacity | L | 240 |
| Main Brush + Side Brush Length | mm | 740+500*4 |
| Power of Main Brush + Fan + Side Brush + Vibration Dust Removal | w | 1500+600+150*4+200*2 |
| Charger & Charging Mode | / | Full-aluminum Intelligent 15A Auto-stop Charger |
| Small Fire Extinguisher | ml | 500 |
| Chassis | / | Engineering Vehicle Chassis |
| Tire | / | 350-8 Solid Rubber Tire*3 |
| Operation Control Mode | / | Full-automatic One-key Control |
| Max. Diameter of Inhalable Particles | mm | 50 |
| Overall Vehicle Weight | kg | 660 |
Vehicle Highlights
Sweeping & Vacuum Function: Completes floor cleaning in one pass for efficient operation.
Single Fan & Single Vibration Motor: Delivers thorough cleaning with lower operating noise.
240L Large-Capacity Waste Bin: Extends continuous working duration per charge.
1500W DC Motor: Compact size, high efficiency and reliable performance.
Solid Reinforced Wide Engineering Tires: Ensures stable & safe driving; eliminates frequent tire patching/replacement.
Hydraulic Disc Brake System: Provides stable and secure braking performance.
Full Plastic Sprayed Body: Smooth, bright finish with excellent fade resistance.
Modular Construction: All components support quick disassembly for easy routine inspection & maintenance.
Curved Front Windshield: Optimizes driving view to improve driving safety.
15AH Intelligent Charger: Features automatic power cut-off protection when fully charged.
